Polytetrafluoroethylene (PTFE), widely known under the trade name Teflon, has long since developed from its original application as a non-stick coating for cookware into one of the most important high-performance engineering materials. As an unbranched, linear and semi-crystalline polymer of fluorine and carbon, PTFE combines an extraordinary combination of properties that make it ideal for the most demanding technical applications.
Molecular architecture as the basis for superior properties
The extraordinary properties of PTFE begin at the molecular level. The C-F bonds in the polymer are among the strongest known chemical bonds and are effectively shielded by the complete coating of the carbon skeleton with fluorine atoms (Wikipedia, 2025). This dense “protective shield” stabilizes the molecular chains against chemical attacks and thermal stress and prevents unwanted interactions with the environment.
PTFE is semi-crystalline with a degree of crystallinity of typically 50-90% – technical grades even reach values of around 90%. The amorphous proportion is accordingly only around 10%. This highly pronounced crystal structure manifests itself in characteristic melt and crystal-crystal transitions and forms the basis for the excellent behavior under mechanical, thermal and chemical stress.
Thermal properties in detail
The peak maximum of the melting of PTFE is around 327°C, while at 19°C a transformation from triclinic to hexagonal crystallite structure takes place, combined with an approx. 1% increase in volume (pro-K, 2020). Particularly noteworthy is the glass transition temperaturewhich varies between -100°C and 134°C depending on the measurement method. The low Tg in the main polymer strand enables exceptional flexibility at very low temperatures – PTFE remains ductile even in liquid helium.
The thermal stability is demonstrated in a continuous operating temperature range of -200°C to 260°C, whereby short-term maximum temperatures up to the melting range are possible. The low thermal conductivity of around 0.25 W/(m-K) and high specific specific heat capacity support the excellent insulating properties (Wikipedia, 2025).
Chemical resistance and mechanical properties
PTFE is practically inert to almost all aggressive chemicals. Even concentrated acids, bases and solvents hardly attack the polymer. Only very reactive reducing agents such as alkaline metals in ammonia and fluorinating media at high temperatures are exceptions (pro-K, 2020).
Mechanically, PTFE is characterized by a remarkably low surface energy, resulting in the lowest coefficient of friction of all engineering plastics – often described as “gliding like wet ice on wet ice” (Klein, 2005). The typical Shore D hardness is 50-72, the tensile strength is 22-40 N/mm² and the density is 2.1-2.3 g/cm³. The mechanical strength can be significantly increased by reinforcing with glass, carbon or bronze fibers.
Variety of PTFE variants
The adaptability of PTFE is demonstrated by the wide range of variants available. Unfilled PTFE offers the highest chemical resistance and best sliding properties. Filled PTFE compounds with glass, carbon, graphite, bronze or MoS₂ particles enable targeted adjustments to hardness, stiffness, thermal conductivity and wear behavior.
Expanded PTFE (ePTFE) with its mechanically stretched, porous structure shows outstanding strength and improved cold flow. Well-known applications include Gore-Tex membranes, seals and filter media. Copolymers such as FEP (perfluoroethylene propylene), PFA (perfluoroalkoxy) and MFA (modified PTFE) specifically optimize individual properties such as weldability, transparency or thermal stability.
Processing technologies and surface modification
The processing of PTFE requires special technologies, as the material is not melt-flowable and therefore cannot be processed like thermoplastics. The most important processing methods include ram extrusion, in which PTFE powder is pressed through a nozzle under high pressure, and sintering, in which preformed parts are compacted at temperatures just below the melting range (Klein, 2005). Paste extrusion enables the production of thin films and tapes by adding auxiliary materials, while compression molding is used for more complex geometries.
Special challenges arise when modifying the surface of PTFE, as the low surface energy results in poor wettability and adhesion. Plasma treatment, chemical etching with sodium naphthalene solution or corona treatment can specifically increase the surface energy and thus improve bondability or coatability (pro-K, 2020). These processes selectively remove fluorine atoms from the surface and create reactive centers for better bonding.
The tribological properties of PTFE are reflected in extremely low coefficients of friction of 0.04-0.10 against steel, whereby the exact value depends on surface roughness, load and sliding speed (Klein, 2005). The wear mechanism is predominantly adhesive, whereby PTFE particles are transferred to the mating surface where they form a lubricating layer. The characteristic stick-slip behavior at low speeds can be reduced by fillers or special surface treatments.
Technical applications in an industrial environment
The wide range of properties of PTFE allows it to be used in numerous high-performance technical applications. In chemical plant engineering, pharmaceuticals and food technology, PTFE seals, shaft seals and bellows are used where aggressive media would attack conventional materials. In industrial furnaces, plain bearings and conveyor technology, PTFE ensures minimal friction under high mechanical loads without generating wear products (Klein, 2005).
In electrical engineering, the low dielectric constant and high dielectric strength are used for insulators, cable sheathing and high-frequency technology. Medical technology benefits from its biocompatibility and inertness for vascular prostheses and implants. Textile membranes for outdoor clothing as well as roof and façade materials benefit from the UV stability and insensitivity to environmental chemicals.
Specialized industries
In the aerospace industryPTFE proves its worth in extreme temperature fluctuations and aggressive fuels. O-rings and seals made of PTFE function reliably from -200°C to +260°C and withstand hydrazine, nitrogen tetroxide and other rocket propellants. Electrical insulators made of PTFE show constant dielectric properties even under cosmic radiation and vacuum.
The semiconductor industry uses PTFE to meet the highest purity requirements. Components for etching processes, cleanroom fittings and fluid lines benefit from its chemical inertness to hydrofluoric acid, aqua regia and other aggressive etching media. The low ion release and particle generation make PTFE indispensable for sub-micrometer manufacturing processes.
In the automotive industryPTFE gaskets are used in fuel systems, gearboxes and air conditioning systems. Modern gasoline direct injection requires sealing materials that can withstand both modern biofuels and additives. PTFE diaphragms in sensors enable precise pressure measurements with simultaneous chemical resistance.
Offshore and marine technology uses PTFE for corrosion protection and seawater-resistant components. Valve seals, pipes and pump parts made of PTFE can withstand years of aggressive seawater and chemicals that inhibit bio-growth without any loss of performance.
Current research and development
Modern research approaches focus on the targeted development of PTFE-based compounds by combining them with long or short fiber-reinforced systems. This enables the design to meet the highest tribological, mechanical or thermal requirements. New analytical methods offer precise insights into glass transitionscrystallinity and the interaction of amorphous and crystalline phases.
PTFE nanocomposites with nanoparticles such as hydroxyapatite show superior sliding behavior, reduced wear and are promising candidates for arthroplasty. Expanded PTFE continues to develop as a high-quality implant material for vascular prostheses with improved biocompatibility.
Sustainability and recycling challenges
Despite its chemical inertness, PTFE is fundamentally recyclable. The processes used range from mechanical recycling and ram extrusion to innovative upcycling technologies with recovery rates of up to 85%. However, recycling is technically challenging, as the high melting range and chemical resistance require special processes.
The development of sustainable alternatives and the optimization of recycling processes are increasingly in focus. At the same time, the substitution of rare or environmentally critical additives is becoming increasingly important in order to reduce the ecological footprint.
Processing limitations and regulatory aspects
Compared to other high-performance plastics, PTFE shows limitations under dynamic or prolonged stress and tends to deform due to creep. Ultra-high precision and tight tolerances therefore remain a challenge that requires special processing techniques. The high processing temperatures also limit the coating of temperature-sensitive substrates.
Depending on the area of application, PTFE products must meet various standards: FDA for food contact, ISO 10993 for biocompatibility or ASTM D3302 for chemical resistance. These regulatory requirements influence both the development and the approval of specific formulations.
Comparative material analysis
PTFE versus other fluoropolymers
The fluoropolymer family offers different property profiles for specific applications. FEP (perfluoroethylene propylene) has similar chemical resistance to PTFE, but is melt-processable and therefore suitable for more complex geometries. The continuous operating temperature range is somewhat lower at 200°C, but precise injection molded parts and films are possible.
PFA (perfluoroalkoxy) combines the melt processability of FEP with higher temperature resistance up to 260°C. The mechanical properties outperform PTFE at elevated temperatures, but at a higher material cost. ETFE (ethylene tetrafluoroethylene) offers superior mechanical strength and radiation resistance, but without the extreme chemical and tribological properties of PTFE.
Cost analysis and profitability
PTFE is one of the more expensive engineering plastics with raw material costs of €8-15/kg compared to €2-4/kg for standard engineering plastics. However, these additional costs are offset by the exceptionally long service life and freedom from maintenance. In critical applications, PTFE components can achieve operating times of 10-20 years, while alternative materials require annual replacement (pro-K, 2020).
The total cost of ownership must include downtime, maintenance costs and productivity losses. In the chemical industry, unplanned plant downtimes due to defective seals can cause costs of €10,000-100,000 per day, which means that premium materials quickly pay for themselves.
Limitations and weak points
Despite its outstanding properties, PTFE has characteristic weaknesses. Its mechanical strength is limited, especially under dynamic load. Creep deformation under load and low wear resistance under dry friction often require constructive measures or fillers.
Processing limitations result from the lack of melt flowability. Complex geometries, undercuts and thin-walled structures are difficult to realize. The high sintering temperatures also limit applications on temperature-resistant substrates.
Temperature shock can lead to cracking in PTFE , as the crystal-to-crystal transition at 19°C is accompanied by a volume jump. Rapid temperature changes through this critical zone should be avoided.
The surface properties with extremely low surface energy prevent bonding and coating without special pre-treatment. This limits composite constructions and repair options.
Environmental aspects are becoming increasingly important. PTFE belongs to the PFAS family (perfluorinated and polyfluorinated alkyl substances), which are the subject of critical debate due to their persistence and bioaccumulation. Stricter regulations could restrict future applications and favor alternative materials.
Conclusion for research and development
PTFE has established itself as an indispensable high-performance technical material that has grown far beyond its original application. Its unique combination of chemical and thermal stability, low surface energy and versatile modifiability makes it indispensable for the most demanding applications. Despite challenges in sustainability and processing, PTFE remains the first choice for extreme conditions, while at the same time innovative approaches in recycling, nanocomposites and sustainable material development are opening up new perspectives.
Bibliography
Wikipedia (2025): Polytetrafluoroethylene. Retrieved 20.08.2025 from:
https://de.wikipedia.org/wiki/Polytetrafluorethylen
pro-K (2020): Introduction to the processing of PTFE plastics, Fachgruppe Fluoropolymergroup, February 2020. Retrieved from:
https://www.pro-kunststoff.de/assets/Merkbl%C3%A4tter%20und%20Co/TM%2002%20Einf%C3%BChrung%20in%20die%20Verarbeitung%20von%20PTFE-Kunststoffen%20(Februar%202020).pdf
Klein, P. (2005): Tribological property profile of short-fiber-reinforced polytetrafluoroethylene/polyetheretherketone composites. Dissertation, TU Kaiserslautern. Retrieved from:
https://kluedo.ub.rptu.de/files/4730/_Klein+2005+-+Tribologisches+Eigenschaftsprofil+kurzfaserverstärkter+Polytetrafluorethylen.pdf
